Model |
|
Print Specification |
| Print speed(A4/LTR) |
18ppm(A4) ； 19ppm(LTR) |
| Duplex Print speed |
6ppm(A4) /6ppm(LTR) |
| First print out time |
Mono：10s；Color：11s |
| Printer language |
PCL6/PS3 |
| Processor speed |
1GHz |
| Memory |
1GB |
| Recommended monthly page volume |
300-1500 Pages |
| Maximun Monthly duty cycle |
30000 Pages |
| Control panel |
3.5 inch touch screen |
| Other printer function |
Watermark Printing Poster Printing Multi-page in one Printing Brochure Printing One step driver installation |
| Direct USB |
YES |
| Standard Ports |
USB2.0(High Speed) IEEE802.3 10 /100Base-Tx IEEE802.11b/g/n(support WPS) |
| Mobile print |
Airprint ; Mopria ; Pantum App |
| Duplex Printing |
Auto |
|
Paper handling |
| Paper Input Capacity |
250 Pages |
| Multipurpose tray |
1 Page |
| Paper output capacity |
100 Pages |
| Media types |
Plain:70~105g/m² (Including 105g/m²) Thin:60~70g/m² (Not including 70g/m²) Thick:105~200g/m² (Not including 105g/m²) Transparency/Cardstock/Label/Envelope |
| Media sizes |
A4、 Letter、 Legal、 Folio、 Oficio、 JIS B5、 ISO B5、 Executive、 Statement、 A5、Big 16K、16K、Big 32K、32K、 A6、 No.10 Env、 Monarch Env、 DL Env(Envelope No. 5)、 C5 Env(Envelope No. 7)、 C6 Env、 Yougata4、 Younaga3、 Nagagata3、 Yougata2、 ZL (Envelope No. 6)、 Postcard、B6、 Japanese Postcard Custom: minimum 96x148mm~maximum 216x356mm |
| Media weights |
Standrad tray：60~200g/㎡ Multipurpose tray：60~105g/㎡ |
|
Copy Specification |
| Copy color |
color/black |
| Copy speed |
18ppm |
| First copy out time |
FB：16s ADF：18s |
| Max.copy page |
99Pages |
| Copy reduce / enlarge settings |
25%-400% |
| Copy function |
ID copy Receipt copy N-up copy Clone copy poster copy |
|
Scan Specification |
| Scanner type |
FB+ADF |
| Scan mode |
Color、Gray、Monochrome (PC only) |
| Scan technology |
CIS |
| ADF scan speed |
18ppm (300*300 dpi) |
| Scan to |
PC/Email/FTP/USB flash disk /ios/Android |
| ADF capacity |
50Pages |
| Scan to USB |
Yes |
| Format |
JPEG、TIFF、PDF |
| Color scaning |
Yes |
|
General |
| Printer Dimensions（W×D×H) |
401*411*358mm |
| Weight(with cartridge ) |
19.4kg |
| Package Dimensions（W×D×H) |
535*555*456mm |
| Total Weight(Include Printer ,cartridge and package ) |
22.1kg |
| Noise Level |
print/scan≤52dBA copy≤54dBA Mute≤47dBA standby≤30dBA |
| Power consumption |
Print Average：≤380W Standby: ≤10W Dormant：≤1W Off：≤0.15W |
| Power |
AC 110-127V，50Hz/60Hz，7A AC 220-240V，50Hz/60Hz，3.5A |
| Print environment |
Operating temperature：10-32℃;Relative humidity：20% ～ 80%RH;Altitude：≤2000m |
| Operating system compatibility |
Windows XP/Windows7/Windows8/Windows8.1/Windows10/Windows 11/Windows server/2012/2016(32bit/64bit) ; Mac10.9～12 ; ubuntu16.04、18.04、20.04 |
|
Consumable |
| Consumable type |
One-piece |
| Starter cartridge |
CTL-1100K：1000Pages CTL-1100C/CTL-1100M/CTL-1100Y：700Pages |
| Cartridge model and yiled |
①CTL-1100K：1000Pages、CTL-1100C/CTL-1100M/CTL-1100Y：700Pages ②CTL-1100HK：2000Pages、CTL-1100HC/CTL-1100HM/CTL-1100HY：1500Pages ③CTL-1100XK：3000Pages、CTL-1100XC/CTL-1100XM/CTL-1100XY：2300Pages |
| Waste powder bottle |
CWT-1100：15000Pages |
| Note |
(1)The toner cartridge capacity is the average print volume of the toner cartridge during continuous printing in the single-sided mode, based on the ISO/IEC 19798 standard. Actual print volume may vary based on other factors such as paper size and feed direction, toner coverage, tray source, percentage of black-only printing, and average print job complexity |
|
